ARFF vehicle (Aircraft Rescue and Fire Fighting)
Vehicles meeting ICAO intervention requirements for Aircraft crash fires at airports.
Classified ARFF vehicle (Aircraft Rescue and Fire Fighting) 24, 40, 60, 90, they respond rapidly with the required means of action: Water, foam, powder.
General specifications
Chassis
- MAN - 4x4 (VIM 24 VIM 27) /Engine power: 440 HP
- MAN - 6x6 (VIM 60 VIM 68) /Engine power: 540 HP
- MERCEDES - 6x6 (VIM 90)/Engine power: 580 HP
Equipment
- 🔴 VIM 24 - VIM 27
- Water tank (GRP): 2400-2700 litres
- Foam compound tank (GRP): 380 litres
- Auxiliary engine driven pump (centrifugal pump) @ 13 bar: maintenance-free, automatic priming (aluminium or bronze) - 2800 lpm
- Dual flow monitor: 2500 lpm / 1250 lpm
- 🔴 VIM 60 - VIM 68
- Water tank (GRP): 6000-6800 litres
- Foam compound tank (GRP): 920 litres
- Auxiliary engine driven pump (centrifugal pump) @ 13 bar: Aluminium or bronze - 5 400 lpm
- Dual flow monitor: monitor/min-1500 lpm
- 🔴 VIM 90
- Water tank (GRP): 9000 litres
- Foam compound tank (GRP): 1100 litres
- Auxiliary engine driven pump (centrifugal pump) @ 13 bar: Aluminium or bronze - 5 400 lpm
- Dual flow monitor: monitor/min-2000 lpm
- 🔴 ALL ICAO ARFF VEHICLES
- 2-seats cab
- Aluminium structure with 2 doors/adjustable holders for accessories
- Around the pump GIMAEX proportioning system
- DC Powder: 250kg of DC powder - Nitrogen or CO2 gas
- 1 DN45 outlet with foam monitor/1 DN70 outlet
- 1 front-swivelling reel fitted with 30 metres of semi-rigid DN33 hose with variable-delivery foam branch pipe
- Additional air compressor
- Roller ladder support
- CAN-Bus system …/ controlled by screen in cab/LED area lightning
Numerous options and adaptations available, to be jointly defined by the users and our engineers.
